Absolute Pressure Absolute Series APA
Absolute Pressure Absolute Series APA
New
The ABSOLUTE series switches cover all the industrial application thanks to its wide pressure ranges.
Unique and special design of the measuring cell guarantees high performances.
Absolute Pressure
Absolute pressure switches are ideal process devices in various industrial sectors.
The HIGH QUALITY guarantees HIGH levels of availability and they are ideal for Safety Instrumented Systems (IEC 61508) as well as for process control.
The instruments are ATEX certified.
NACE, Off-shore, Tropical, Ammonia execution and special wetted materials are available.
The ABSOLUTE series switches cover all the industrial application thanks to its wide pressure ranges.
Unique and special design of the measuring cell guarantees high performances.
Unique and special design of the measuring cell guarantees high performances.
| Enclosure | IP 65 stainless steel or aluminium (Ex-d) |
| Protection mode | Ex-ia, Ex-d |
| Contacts | 1 SPDT, 2 independent SPD - fixed or adjustable dead-band |
| Repeatability | better than 1% |
Absolute Pressure
Absolute Series APA
|
Model
|
APA10
low ranges |
APA
|
|
|
Execution
|
ATEX Ex-d GAS & Ex-tD DUST
Explosion-proof |
||
|
Enclosure
|
IP 65 cast aluminium alloy
|
||
|
Contacts
|
1 SPDT or 2 independent SPDT – silver or gold contacts - fixed or adjustable dead band
|
||
|
Reference pressure
|
Absolute pressure
|
||
|
Setting Ranges
|
mbar abs
|
0/25; 0/40; 0/60
|
0/160; 0/250; 0/400; 0/600; 0/1000
|
|
Dimensions
|
150x190x320 mm
|
150x150x250 mm
|
|
|
Weight
|
10,0 kg
|
7,2 kg
|
|
|
Certificates/ approvals
|
EC declaration ATEX GOST R
|
||
